Quick Saver GR-S

Electronic Component Factory
Food Factory
Medical Equipment Factory
  • High speed, smooth operation
  • Orange curtain is not only see-through but insect prevention also
  • Opening and closing speed is 10 times faster than usual shutter.
  • Curtain's maximum size can be up to WxH = 6x5 m. Maximum opening speed is 1m/s, maximum closing speed is 0.5m/s
  • Open/close continuously in 60 cycles per hour
  • The support bone structure in curtain helps Quick Saver increase the wind pressure resisstance. Wind pressure resistance is 157 Pa.
  • Capacity: 0.75 KW
  • Electricity supply: 1PH.220V.50Hz
  • Suitable for large entrance and next-to outdoor area
Curtain samples:
